Technical Specifications of NTB45N06LT4G
| Datasheet |  NTB45N06LT4G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Digi-Reel? |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 60V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 45A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 28 mOhm @ 22.5A, 5V |
|---|
| Vgs(th) (Max) @ Id | 2V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 32nC @ 5V |
|---|
| Input Capacitance (Ciss) @ Vds | 1700pF @ 25V |
|---|
| Power - Max | 2.4W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | D2PAK |
|---|
We can supply ON Semiconductor part# NTB45N06LT4G. Use the request quote form to request NTB45N06LT4G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NTB45N06LT4G. The price and lead time for NTB45N06LT4G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NTB45N06LT4G. We look forward to doing business with you.
