Technical Specifications of IPB120N04S3-02
| Datasheet |  IPB120N04S3-02 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | OptiMOS? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 40V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 120A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 2 mOhm @ 80A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 230μA |
|---|
| Gate Charge (Qg) @ Vgs | 210nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 14300pF @ 25V |
|---|
| Power - Max | 300W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | PG-TO263-2 |
|---|
We can supply Infineon Technologies part# IPB120N04S3-02. Use the request quote form to request IPB120N04S3-02 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IPB120N04S3-02. The price and lead time for IPB120N04S3-02 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IPB120N04S3-02. We look forward to doing business with you.
