HUFA76429D3ST_F085
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HUFA76429D3ST_F085 |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Description | MOSFET N-CH 60V 20A DPAK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HUFA76429D3ST_F085 Price |  |
Technical Specifications of HUFA76429D3ST_F085
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Fairchild Semiconductor |
| Series | UltraFET? |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Tc) |
| Rds On (Max) @ Id, Vgs | 23 mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 250μA |
| Gate Charge (Qg) @ Vgs | 46nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 1480pF @ 25V |
| Power - Max | 110W |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | D-Pak |
