Technical Specifications of APT26F120L
| Datasheet |  APT26F120L datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
|---|
| Current - Continuous Drain (Id) @ 25°C | 27A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 650 mOhm @ 14A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
|---|
| Gate Charge (Qg) @ Vgs | 300nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 9670pF @ 25V |
|---|
| Power - Max | 1135W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-264-3, TO-264AA |
|---|
| Supplier Device Package | TO-264 [L] |
|---|
We can supply Microsemi Corporation part# APT26F120L. Use the request quote form to request APT26F120L pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT26F120L. The price and lead time for APT26F120L depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT26F120L. We look forward to doing business with you.
