Technical Specifications of APTGF100DA120TG
| Datasheet |  APTGF100DA120TG datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| IGBT Type | NPT |
|---|
| Configuration | Single |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 135A |
|---|
| Power - Max | 568W |
|---|
| Vce(on) (Max) @ Vge, Ic | 3.7V @ 15V, 100A |
|---|
| Current - Collector Cutoff (Max) | 350μA |
|---|
| Input Capacitance (Cies) @ Vce | 6.9nF @ 25V |
|---|
| Input | Standard |
|---|
| NTC Thermistor | Yes |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SP4 |
|---|
| Supplier Device Package | SP4 |
|---|
We can supply Microsemi Corporation part# APTGF100DA120TG. Use the request quote form to request APTGF100DA120TG pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APTGF100DA120TG. The price and lead time for APTGF100DA120TG depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APTGF100DA120TG. We look forward to doing business with you.
