Technical Specifications of VS-GB90DA120U
| Datasheet |  VS-GB90DA120U datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Vishay Semiconductor Diodes Division |
|---|
| Series | - |
|---|
| IGBT Type | NPT |
|---|
| Configuration | Single |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 149A |
|---|
| Power - Max | 862W |
|---|
| Vce(on) (Max) @ Vge, Ic | 3.8V @ 15V, 75A |
|---|
| Current - Collector Cutoff (Max) | 250μA |
|---|
| Input Capacitance (Cies) @ Vce | - |
|---|
| Input | Standard |
|---|
| NTC Thermistor | No |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SOT-227-4, miniBLOC |
|---|
| Supplier Device Package | SOT-227 |
|---|
We can supply Vishay Semiconductor Diodes Division part# VS-GB90DA120U. Use the request quote form to request VS-GB90DA120U pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VS-GB90DA120U. The price and lead time for VS-GB90DA120U depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# VS-GB90DA120U. We look forward to doing business with you.
