Technical Specifications of APT75GP120J
| Datasheet |  APT75GP120J datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | POWER MOS 7? |
|---|
| Part Status | Active |
|---|
| IGBT Type | PT |
|---|
| Configuration | Single |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 128A |
|---|
| Power - Max | 543W |
|---|
| Vce(on) (Max) @ Vge, Ic | 3.9V @ 15V, 75A |
|---|
| Current - Collector Cutoff (Max) | 1mA |
|---|
| Input Capacitance (Cies) @ Vce | 7.04nF @ 25V |
|---|
| Input | Standard |
|---|
| NTC Thermistor | No |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | ISOTOP |
|---|
| Supplier Device Package | ISOTOP? |
|---|
We can supply Microsemi Corporation part# APT75GP120J. Use the request quote form to request APT75GP120J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT75GP120J. The price and lead time for APT75GP120J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT75GP120J. We look forward to doing business with you.
