Technical Specifications of SGH80N60UFDTU
| Datasheet |  SGH80N60UFDTU datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 80A |
|---|
| Current - Collector Pulsed (Icm) | 220A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.6V @ 15V, 40A |
|---|
| Power - Max | 195W |
|---|
| Switching Energy | 570μJ (on), 590μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 175nC |
|---|
| Td (on/off) @ 25°C | 23ns/90ns |
|---|
| Test Condition | 300V, 40A, 5 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 95ns |
|---|
| Package / Case | TO-3P-3, SC-65-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-3PN |
|---|
