Technical Specifications of FGD4536TM
| Datasheet |  FGD4536TM datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Cut Tape (CT) |
|---|
| IGBT Type | Trench |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 360V |
|---|
| Current - Collector (Ic) (Max) | - |
|---|
| Current - Collector Pulsed (Icm) | 220A |
|---|
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 50A |
|---|
| Power - Max | 125W |
|---|
| Switching Energy | - |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 47nC |
|---|
| Td (on/off) @ 25°C | - |
|---|
| Test Condition | - |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | D-Pak |
|---|
We can supply Fairchild Semiconductor part# FGD4536TM. Use the request quote form to request FGD4536TM pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FGD4536TM. The price and lead time for FGD4536TM depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FGD4536TM. We look forward to doing business with you.
