Technical Specifications of AOK50B65M2
| Datasheet |  AOK50B65M2 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Alpha & Omega Semiconductor Inc. |
|---|
| Series | Alpha IGBT? |
|---|
| Packaging | Tube |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 100A |
|---|
| Current - Collector Pulsed (Icm) | 150A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 50A |
|---|
| Power - Max | 500W |
|---|
| Switching Energy | 2.09mJ (on), 1.03mJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 102nC |
|---|
| Td (on/off) @ 25°C | 46ns/182ns |
|---|
| Test Condition | 400V, 50A, 6 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 327ns |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-247 |
|---|
We can supply Alpha & Omega Semiconductor Inc. part# AOK50B65M2. Use the request quote form to request AOK50B65M2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AOK50B65M2. The price and lead time for AOK50B65M2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AOK50B65M2. We look forward to doing business with you.
