Technical Specifications of AOD5B65M1
| Datasheet |  AOD5B65M1 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Alpha & Omega Semiconductor Inc. |
|---|
| Series | Alpha IGBT? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 10A |
|---|
| Current - Collector Pulsed (Icm) | 15A |
|---|
| Vce(on) (Max) @ Vge, Ic | 1.98V @ 15V, 5A |
|---|
| Power - Max | 69W |
|---|
| Switching Energy | 80μJ (on), 70μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 14nC |
|---|
| Td (on/off) @ 25°C | 8.5ns/106ns |
|---|
| Test Condition | 400V, 5A, 60 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 195ns |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | TO-252 |
|---|
We can supply Alpha & Omega Semiconductor Inc. part# AOD5B65M1. Use the request quote form to request AOD5B65M1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AOD5B65M1. The price and lead time for AOD5B65M1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AOD5B65M1. We look forward to doing business with you.
