Technical Specifications of APT40GR120S
| Datasheet |  APT40GR120S datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | NPT |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 88A |
|---|
| Current - Collector Pulsed (Icm) | 160A |
|---|
| Vce(on) (Max) @ Vge, Ic | 3.2V @ 15V, 40A |
|---|
| Power - Max | 500W |
|---|
| Switching Energy | 1.38mJ (on), 906μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 210nC |
|---|
| Td (on/off) @ 25°C | 22ns/163ns |
|---|
| Test Condition | 600V, 40A, 4.3 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | D3Pak |
|---|
We can supply Microsemi Corporation part# APT40GR120S. Use the request quote form to request APT40GR120S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT40GR120S. The price and lead time for APT40GR120S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT40GR120S. We look forward to doing business with you.
