Technical Specifications of FGP5N60LS
| Datasheet |  FGP5N60LS datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | Field Stop |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 10A |
|---|
| Current - Collector Pulsed (Icm) | 36A |
|---|
| Vce(on) (Max) @ Vge, Ic | 3.2V @ 12V, 14A |
|---|
| Power - Max | 83W |
|---|
| Switching Energy | 38μJ (on), 130μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 18.3nC |
|---|
| Td (on/off) @ 25°C | 4.3ns/36ns |
|---|
| Test Condition | 400V, 5A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-220-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-220-3 |
|---|
We can supply Fairchild Semiconductor part# FGP5N60LS. Use the request quote form to request FGP5N60LS pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FGP5N60LS. The price and lead time for FGP5N60LS depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FGP5N60LS. We look forward to doing business with you.
