Technical Specifications of NGTB60N65FL2WG
| Datasheet |  NGTB60N65FL2WG datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | Field Stop |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 100A |
|---|
| Current - Collector Pulsed (Icm) | 240A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 60A |
|---|
| Power - Max | 595W |
|---|
| Switching Energy | 1.59mJ (on), 660μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 318nC |
|---|
| Td (on/off) @ 25°C | 117ns/265ns |
|---|
| Test Condition | 400V, 60A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 96ns |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | TO-247-3 |
|---|
We can supply ON Semiconductor part# NGTB60N65FL2WG. Use the request quote form to request NGTB60N65FL2WG pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NGTB60N65FL2WG. The price and lead time for NGTB60N65FL2WG depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NGTB60N65FL2WG. We look forward to doing business with you.
