Technical Specifications of RGT40TS65DGC11
| Datasheet |  RGT40TS65DGC11 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Rohm Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | Trench Field Stop |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 40A |
|---|
| Current - Collector Pulsed (Icm) | 60A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 20A |
|---|
| Power - Max | 144W |
|---|
| Switching Energy | - |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 40nC |
|---|
| Td (on/off) @ 25°C | 22ns/75ns |
|---|
| Test Condition | 400V, 20A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 58ns |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-247N |
|---|
We can supply Rohm Semiconductor part# RGT40TS65DGC11. Use the request quote form to request RGT40TS65DGC11 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number RGT40TS65DGC11. The price and lead time for RGT40TS65DGC11 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# RGT40TS65DGC11. We look forward to doing business with you.
