Technical Specifications of FGH60N60SFTU
| Datasheet |  FGH60N60SFTU datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | Field Stop |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 120A |
|---|
| Current - Collector Pulsed (Icm) | 180A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.9V @ 15V, 60A |
|---|
| Power - Max | 378W |
|---|
| Switching Energy | 1.79mJ (on), 670μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 198nC |
|---|
| Td (on/off) @ 25°C | 22ns/134ns |
|---|
| Test Condition | 400V, 60A, 5 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-247 |
|---|
We can supply Fairchild Semiconductor part# FGH60N60SFTU. Use the request quote form to request FGH60N60SFTU pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FGH60N60SFTU. The price and lead time for FGH60N60SFTU depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FGH60N60SFTU. We look forward to doing business with you.
