Technical Specifications of APT45GR65SSCD10
| Datasheet |  APT45GR65SSCD10 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| IGBT Type | NPT |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 118A |
|---|
| Current - Collector Pulsed (Icm) | 224A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 45A |
|---|
| Power - Max | 543W |
|---|
| Switching Energy | * |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 203nC |
|---|
| Td (on/off) @ 25°C | 15ns/100ns |
|---|
| Test Condition | 433V, 45A, 4.3 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 80ns |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | D3Pak |
|---|
We can supply Microsemi Corporation part# APT45GR65SSCD10. Use the request quote form to request APT45GR65SSCD10 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT45GR65SSCD10. The price and lead time for APT45GR65SSCD10 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT45GR65SSCD10. We look forward to doing business with you.
