Technical Specifications of KDE2406PHV1 MS.A.GN
| Datasheet |  KDE2406PHV1 MS.A.GN datasheet |
|---|
| Category | Fans, Thermal Management |
|---|
| Family | DC Fans |
|---|
| Manufacturer | Sunon Fans |
|---|
| Series | MagLev? |
|---|
| Voltage - Rated | 24VDC |
|---|
| Size / Dimension | Square - 60mm L x 60mm H |
|---|
| Width | 15.00mm |
|---|
| Air Flow | 21.0 CFM (0.595m3/min) |
|---|
| Static Pressure | 0.180 in H2O (44.8 Pa) |
|---|
| Bearing Type | Vapo-Bearing? |
|---|
| Fan Type | Tubeaxial |
|---|
| Features | - |
|---|
| Noise | 36 dB(A) |
|---|
| Power (Watts) | 1.90W |
|---|
| RPM | 4300 RPM |
|---|
| Termination | 2 Wire Leads |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
|---|
| Approvals | CE, CUR, TUV, UL |
|---|
| Current Rating | 0.080A |
|---|
| Voltage Range | 13.8 ~ 27.6VDC |
|---|
| Material - Frame | Polybutylene Terephthalate (PBT) |
|---|
| Material - Blade | Polybutylene Terephthalate (PBT) |
|---|
| Weight | 0.093 lb (42.18g) |
|---|
We can supply Sunon Fans part# KDE2406PHV1 MS.A.GN. Use the request quote form to request KDE2406PHV1 MS.A.GN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KDE2406PHV1 MS.A.GN. The price and lead time for KDE2406PHV1 MS.A.GN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KDE2406PHV1 MS.A.GN. We look forward to doing business with you.
