Technical Specifications of KDE1212PTB1-6AR
| Category | Fans, Thermal Management |
|---|
| Family | DC Fans |
|---|
| Manufacturer | Sunon Fans |
|---|
| Series | MagLev? |
|---|
| Voltage - Rated | 12VDC |
|---|
| Size / Dimension | Square - 119.5mm L x 119.5mm H |
|---|
| Width | 25.50mm |
|---|
| Air Flow | 90.0 CFM (2.55m3/min) |
|---|
| Static Pressure | 0.280 in H2O (69.7 Pa) |
|---|
| Bearing Type | Ball |
|---|
| Fan Type | Tubeaxial |
|---|
| Features | Locked Rotor Sensor |
|---|
| Noise | 44.5 dB(A) |
|---|
| Power (Watts) | 4.80W |
|---|
| RPM | 3100 RPM |
|---|
| Termination | 3 Wire Leads |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
|---|
| Approvals | * |
|---|
| Current Rating | 0.400A |
|---|
| Voltage Range | 10.2 ~ 13.8VDC |
|---|
| Material - Frame | Polybutylene Terephthalate (PBT) |
|---|
| Material - Blade | Polybutylene Terephthalate (PBT) |
|---|
| Weight | 0.452 lb (205.02g) |
|---|
We can supply Sunon Fans part# KDE1212PTB1-6AR. Use the request quote form to request KDE1212PTB1-6AR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KDE1212PTB1-6AR. The price and lead time for KDE1212PTB1-6AR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KDE1212PTB1-6AR. We look forward to doing business with you.
