Technical Specifications of ATS-02D-109-C3-R1
| Datasheet |  ATS-02D-109-C3-R1 datasheet |
|---|
| Category | Fans, Thermal Management |
|---|
| Family | Thermal - Heat Sinks |
|---|
| Manufacturer | Advanced Thermal Solutions Inc. |
|---|
| Series | pushPIN? |
|---|
| Type | Top Mount |
|---|
| Package Cooled | Assorted (BGA, LGA, CPU, ASIC...) |
|---|
| Attachment Method | Push Pin |
|---|
| Shape | Rectangular, Fins |
|---|
| Length | 2.126" (54.01mm) |
|---|
| Width | 1.575" (40.01mm) |
|---|
| Diameter | - |
|---|
| Height Off Base (Height of Fin) | 0.374" (9.50mm) |
|---|
| Power Dissipation @ Temperature Rise | - |
|---|
| Thermal Resistance @ Forced Air Flow | 27.79°C/W @ 100 LFM |
|---|
| Thermal Resistance @ Natural | - |
|---|
| Material | Aluminum |
|---|
| Material Finish | Blue Anodized |
|---|
We can supply Advanced Thermal Solutions Inc. part# ATS-02D-109-C3-R1. Use the request quote form to request ATS-02D-109-C3-R1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ATS-02D-109-C3-R1. The price and lead time for ATS-02D-109-C3-R1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ATS-02D-109-C3-R1. We look forward to doing business with you.
