Technical Specifications of SRF1260A-2R2Y
| Datasheet |  SRF1260A-2R2Y datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | Automotive, AEC-Q200, SRF1260A |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 8.8μH |
|---|
| Inductance - Connected In Parallel | 2.2μH |
|---|
| Tolerance | ±30% |
|---|
| Current Rating - Parallel | 10.9A |
|---|
| Current Rating - Series | 5.46A |
|---|
| Current Saturation - Parallel | 15A |
|---|
| Current Saturation - Series | 7.5A |
|---|
| DC Resistance (DCR) - Parallel | 8.5 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 33.3 mOhm Max |
|---|
| Shielding | Shielded |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
|---|
| Height | 0.244" (6.20mm) |
|---|
We can supply Bourns Inc. part# SRF1260A-2R2Y. Use the request quote form to request SRF1260A-2R2Y pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SRF1260A-2R2Y. The price and lead time for SRF1260A-2R2Y depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SRF1260A-2R2Y. We look forward to doing business with you.
