Technical Specifications of P0402NL
| Datasheet |  P0402NL datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Pulse Electronics Corporation |
|---|
| Series | Tomcat |
|---|
| Packaging | Tube |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 161.8μH |
|---|
| Inductance - Connected In Parallel | 40.5μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 3.54A |
|---|
| Current Rating - Series | 1.77A |
|---|
| Current Saturation - Parallel | - |
|---|
| Current Saturation - Series | - |
|---|
| DC Resistance (DCR) - Parallel | 53.21 mOhm |
|---|
| DC Resistance (DCR) - Series | 212.8 mOhm |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | -40°C ~ 130°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.715" L x 0.590" W (18.16mm x 14.99mm) |
|---|
| Height | 0.310" (7.87mm) |
|---|
We can supply Pulse Electronics Corporation part# P0402NL. Use the request quote form to request P0402NL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number P0402NL. The price and lead time for P0402NL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# P0402NL. We look forward to doing business with you.
