Technical Specifications of SDQ25-R82-R
| Datasheet |  SDQ25-R82-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Eaton |
|---|
| Series | SDQ |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 2.59μH |
|---|
| Inductance - Connected In Parallel | 648nH |
|---|
| Tolerance | ±30% |
|---|
| Current Rating - Parallel | 3.37A |
|---|
| Current Rating - Series | 1.68A |
|---|
| Current Saturation - Parallel | 5A |
|---|
| Current Saturation - Series | 2.5A |
|---|
| DC Resistance (DCR) - Parallel | 22.1 mOhm |
|---|
| DC Resistance (DCR) - Series | 88.3 mOhm |
|---|
| Shielding | Shielded |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.205" L x 0.205" W (5.20mm x 5.20mm) |
|---|
| Height | 0.098" (2.50mm) |
|---|
We can supply Eaton part# SDQ25-R82-R. Use the request quote form to request SDQ25-R82-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SDQ25-R82-R. The price and lead time for SDQ25-R82-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SDQ25-R82-R. We look forward to doing business with you.
