Technical Specifications of CTX68-1A-R
| Datasheet |  CTX68-1A-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Eaton |
|---|
| Series | OCTA-PAC? PLUS |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 271.5μH |
|---|
| Inductance - Connected In Parallel | 67.87μH |
|---|
| Tolerance | ±25% |
|---|
| Current Rating - Parallel | 920mA |
|---|
| Current Rating - Series | 460mA |
|---|
| Current Saturation - Parallel | 990mA |
|---|
| Current Saturation - Series | 490mA |
|---|
| DC Resistance (DCR) - Parallel | 437 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 1.749 Ohm Max |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.450" L x 0.450" W (11.43mm x 11.43mm) |
|---|
| Height | 0.165" (4.19mm) |
|---|
We can supply Eaton part# CTX68-1A-R. Use the request quote form to request CTX68-1A-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CTX68-1A-R. The price and lead time for CTX68-1A-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CTX68-1A-R. We look forward to doing business with you.
