Technical Specifications of CTX2-3A-R
Datasheet | CTX2-3A-R datasheet |
Category | Inductors, Coils, Chokes |
Family | Arrays, Signal Transformers |
Manufacturer | Eaton |
Series | OCTA-PAC? PLUS |
Packaging | Tape & Reel (TR) |
Part Status | Active |
Number of Coils | 2 |
Inductance - Connected In Series | 8.43μH |
Inductance - Connected In Parallel | 2.11μH |
Tolerance | ±25% |
Current Rating - Parallel | 7.26A |
Current Rating - Series | 3.63A |
Current Saturation - Parallel | 6.43A |
Current Saturation - Series | 3.21A |
DC Resistance (DCR) - Parallel | 7.9 mOhm Max |
DC Resistance (DCR) - Series | 31.7 mOhm Max |
Shielding | Unshielded |
Operating Temperature | -40°C ~ 85°C |
Mounting Type | Surface Mount |
Package / Case | Nonstandard |
Size / Dimension | 0.550" L x 0.550" W (13.97mm x 13.97mm) |
Height | 0.190" (4.83mm) |
We can supply Eaton part# CTX2-3A-R. Use the request quote form to request CTX2-3A-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CTX2-3A-R. The price and lead time for CTX2-3A-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CTX2-3A-R. We look forward to doing business with you.
