Technical Specifications of HPL1005-3N3
| Datasheet |  HPL1005-3N3 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Susumu |
|---|
| Series | HPL |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Type | Thin Film |
|---|
| Material - Core | - |
|---|
| Inductance | 3.3nH |
|---|
| Tolerance | ±0.2nH |
|---|
| Current Rating | 700mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 250 mOhm Max |
|---|
| Q @ Freq | 13 @ 300MHz |
|---|
| Frequency - Self Resonant | 7GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 300MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0402 (1005 Metric) |
|---|
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
|---|
| Height - Seated (Max) | 0.013" (0.33mm) |
|---|
We can supply Susumu part# HPL1005-3N3. Use the request quote form to request HPL1005-3N3 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number HPL1005-3N3. The price and lead time for HPL1005-3N3 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# HPL1005-3N3. We look forward to doing business with you.
