Technical Specifications of 1782-23F
| Datasheet |  1782-23F datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 1782 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Molded |
|---|
| Material - Core | Iron |
|---|
| Inductance | 1.3μH |
|---|
| Tolerance | ±1% |
|---|
| Current Rating | 535mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 220 mOhm Max |
|---|
| Q @ Freq | 25 @ 7.9MHz |
|---|
| Frequency - Self Resonant | 140MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Frequency - Test | 7.9MHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Axial |
|---|
| Size / Dimension | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) |
|---|
| Height - Seated (Max) | - |
|---|
We can supply API Delevan Inc. part# 1782-23F. Use the request quote form to request 1782-23F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 1782-23F. The price and lead time for 1782-23F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 1782-23F. We look forward to doing business with you.
