Technical Specifications of PTHF50-121
| Datasheet |  PTHF50-121 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | PTHF |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Toroidal |
|---|
| Material - Core | Molybdenum Permalloy(MPP) |
|---|
| Inductance | 50μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 4.77A |
|---|
| Current - Saturation | 3.9A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 30 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 4MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 1kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.820" Dia x 0.400" W (20.83mm x 10.16mm) |
|---|
| Height - Seated (Max) | - |
|---|
We can supply API Delevan Inc. part# PTHF50-121. Use the request quote form to request PTHF50-121 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PTHF50-121. The price and lead time for PTHF50-121 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PTHF50-121. We look forward to doing business with you.
