Technical Specifications of PE-0603CD5N1JTT
| Datasheet |  PE-0603CD5N1JTT datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Pulse Electronics Corporation |
|---|
| Series | 0603CD |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ceramic |
|---|
| Inductance | 5.1nH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 700mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 108 mOhm Max |
|---|
| Q @ Freq | 20 @ 250MHz |
|---|
| Frequency - Self Resonant | 5.7GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 250MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0603 (1608 Metric) |
|---|
| Size / Dimension | 0.071" L x 0.049" W (1.80mm x 1.24mm) |
|---|
| Height - Seated (Max) | 0.040" (1.02mm) |
|---|
We can supply Pulse Electronics Corporation part# PE-0603CD5N1JTT. Use the request quote form to request PE-0603CD5N1JTT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PE-0603CD5N1JTT. The price and lead time for PE-0603CD5N1JTT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PE-0603CD5N1JTT. We look forward to doing business with you.
