Technical Specifications of MLG1005S8N2HT000
| Datasheet |  MLG1005S8N2HT000 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | MLG |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Multilayer |
|---|
| Material - Core | Non-Magnetic |
|---|
| Inductance | 8.2nH |
|---|
| Tolerance | ±3% |
|---|
| Current Rating | 500mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 300 mOhm Max |
|---|
| Q @ Freq | 8 @ 100MHz |
|---|
| Frequency - Self Resonant | 3GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 100MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0402 (1005 Metric) |
|---|
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
|---|
| Height - Seated (Max) | 0.022" (0.55mm) |
|---|
We can supply TDK Corporation part# MLG1005S8N2HT000. Use the request quote form to request MLG1005S8N2HT000 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MLG1005S8N2HT000. The price and lead time for MLG1005S8N2HT000 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MLG1005S8N2HT000. We look forward to doing business with you.
