Technical Specifications of PTHF75R-30SM
| Datasheet |  PTHF75R-30SM datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | PTHFR-SM |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Toroidal |
|---|
| Material - Core | Molybdenum Permalloy(MPP) |
|---|
| Inductance | 75μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 1.62A |
|---|
| Current - Saturation | 800mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 130 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 7MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 1kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.440" L x 0.440" W (11.18mm x 11.18mm) |
|---|
| Height - Seated (Max) | 0.400" (10.16mm) |
|---|
We can supply API Delevan Inc. part# PTHF75R-30SM. Use the request quote form to request PTHF75R-30SM pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PTHF75R-30SM. The price and lead time for PTHF75R-30SM depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PTHF75R-30SM. We look forward to doing business with you.
