Technical Specifications of ILC0805ERR12J
| Datasheet |  ILC0805ERR12J datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Vishay Dale |
|---|
| Series | ILC-0805 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Multilayer |
|---|
| Material - Core | Ceramic |
|---|
| Inductance | 120nH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 300mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 950 mOhm Max |
|---|
| Q @ Freq | 13 @ 50MHz |
|---|
| Frequency - Self Resonant | 400MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 50MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0805 (2012 Metric) |
|---|
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
|---|
| Height - Seated (Max) | 0.043" (1.10mm) |
|---|
We can supply Vishay Dale part# ILC0805ERR12J. Use the request quote form to request ILC0805ERR12J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ILC0805ERR12J. The price and lead time for ILC0805ERR12J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ILC0805ERR12J. We look forward to doing business with you.
