Technical Specifications of S4924-565J
| Datasheet |  S4924-565J datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | S4924 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 5.6mH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 61mA |
|---|
| Current - Saturation | 14mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 98.9 Ohm Max |
|---|
| Q @ Freq | 50 @ 250kHz |
|---|
| Frequency - Self Resonant | 1.6MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 250kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.520" L x 0.250" W (13.21mm x 6.35mm) |
|---|
| Height - Seated (Max) | 0.230" (5.84mm) |
|---|
We can supply API Delevan Inc. part# S4924-565J. Use the request quote form to request S4924-565J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number S4924-565J. The price and lead time for S4924-565J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# S4924-565J. We look forward to doing business with you.
