Technical Specifications of ELL-CTV5R6N
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Panasonic Electronic Components |
|---|
| Series | V |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 5.6μH |
|---|
| Tolerance | ±30% |
|---|
| Current Rating | 4.9A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 11 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) |
|---|
| Height - Seated (Max) | 0.177" (4.50mm) |
|---|
We can supply Panasonic Electronic Components part# ELL-CTV5R6N. Use the request quote form to request ELL-CTV5R6N pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ELL-CTV5R6N. The price and lead time for ELL-CTV5R6N depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ELL-CTV5R6N. We look forward to doing business with you.
