Technical Specifications of AISC-0805HQ-30NJ-T
| Datasheet |  AISC-0805HQ-30NJ-T datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Abracon LLC |
|---|
| Series | AISC-0805HQ |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ceramic |
|---|
| Inductance | 30nH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 1.2A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 95 mOhm Max |
|---|
| Q @ Freq | 65 @ 500MHz |
|---|
| Frequency - Self Resonant | 1.95GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 250MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.090" L x 0.068" W (2.29mm x 1.73mm) |
|---|
| Height - Seated (Max) | 0.061" (1.52mm) |
|---|
We can supply Abracon LLC part# AISC-0805HQ-30NJ-T. Use the request quote form to request AISC-0805HQ-30NJ-T pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AISC-0805HQ-30NJ-T. The price and lead time for AISC-0805HQ-30NJ-T depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AISC-0805HQ-30NJ-T. We look forward to doing business with you.
