Technical Specifications of AX97-404R7
| Datasheet |  AX97-404R7 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Triad Magnetics |
|---|
| Series | AX97 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 4.7μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 9.3A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 10 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.634" L x 0.622" W (16.10mm x 15.80mm) |
|---|
| Height - Seated (Max) | 0.284" (7.21mm) |
|---|
We can supply Triad Magnetics part# AX97-404R7. Use the request quote form to request AX97-404R7 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AX97-404R7. The price and lead time for AX97-404R7 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AX97-404R7. We look forward to doing business with you.
