Technical Specifications of SDE1006A-100M
| Datasheet |  SDE1006A-100M datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | SDE1006A |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 10μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 3.8A |
|---|
| Current - Saturation | 4A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 60 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 25MHz |
|---|
| Ratings | AEC-Q200 |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.394" L x 0.354" W (10.00mm x 9.00mm) |
|---|
| Height - Seated (Max) | 0.228" (5.80mm) |
|---|
We can supply Bourns Inc. part# SDE1006A-100M. Use the request quote form to request SDE1006A-100M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SDE1006A-100M. The price and lead time for SDE1006A-100M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SDE1006A-100M. We look forward to doing business with you.
