Technical Specifications of LQW18AN3N0C80D
| Datasheet |  LQW18AN3N0C80D datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Murata Electronics North America |
|---|
| Series | LQW18AN_80 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Non-Magnetic |
|---|
| Inductance | 3nH |
|---|
| Tolerance | ±0.2nH |
|---|
| Current Rating | 670mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 170 mOhm Max |
|---|
| Q @ Freq | 13 @ 250MHz |
|---|
| Frequency - Self Resonant | 15GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 100MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0603 (1608 Metric) |
|---|
| Size / Dimension | 0.065" L x 0.039" W (1.65mm x 0.99mm) |
|---|
| Height - Seated (Max) | 0.039" (1.00mm) |
|---|
We can supply Murata Electronics North America part# LQW18AN3N0C80D. Use the request quote form to request LQW18AN3N0C80D pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LQW18AN3N0C80D. The price and lead time for LQW18AN3N0C80D depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LQW18AN3N0C80D. We look forward to doing business with you.
