Technical Specifications of CD1-5R2-R
| Datasheet |  CD1-5R2-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | CD |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 5.2μH |
|---|
| Tolerance | ±30% |
|---|
| Current Rating | 5.05A |
|---|
| Current - Saturation | 5.5A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 22 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.413" L x 0.409" W (10.50mm x 10.40mm) |
|---|
| Height - Seated (Max) | 0.157" (4.00mm) |
|---|
We can supply Eaton part# CD1-5R2-R. Use the request quote form to request CD1-5R2-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CD1-5R2-R. The price and lead time for CD1-5R2-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CD1-5R2-R. We look forward to doing business with you.
