Technical Specifications of CTX10-7-52-R
| Datasheet |  CTX10-7-52-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | CTX |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Toroidal |
|---|
| Material - Core | Powdered Iron |
|---|
| Inductance | 10μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 11.4A |
|---|
| Current - Saturation | 13.5A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 8 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 75°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 1.012" Dia x 0.709" W (25.70mm x 18.00mm) |
|---|
| Height - Seated (Max) | - |
|---|
We can supply Eaton part# CTX10-7-52-R. Use the request quote form to request CTX10-7-52-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CTX10-7-52-R. The price and lead time for CTX10-7-52-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CTX10-7-52-R. We look forward to doing business with you.
