Technical Specifications of CDRH2D09NP-5R6MC
| Datasheet |  CDRH2D09NP-5R6MC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Sumida America Components Inc. |
|---|
| Series | CDRH2D09 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 5.6μH |
|---|
| Tolerance | ±25% |
|---|
| Current Rating | 590mA |
|---|
| Current - Saturation | 370mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 320 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
|---|
| Height - Seated (Max) | 0.039" (1.00mm) |
|---|
We can supply Sumida America Components Inc. part# CDRH2D09NP-5R6MC. Use the request quote form to request CDRH2D09NP-5R6MC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CDRH2D09NP-5R6MC. The price and lead time for CDRH2D09NP-5R6MC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CDRH2D09NP-5R6MC. We look forward to doing business with you.
