Technical Specifications of MLP2520H2R2MT0S1
| Datasheet |  MLP2520H2R2MT0S1 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | MLP |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Multilayer |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 2.2μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 1.3A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 117 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 2MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 1008 (2520 Metric) |
|---|
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
|---|
| Height - Seated (Max) | 0.047" (1.20mm) |
|---|
We can supply TDK Corporation part# MLP2520H2R2MT0S1. Use the request quote form to request MLP2520H2R2MT0S1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MLP2520H2R2MT0S1. The price and lead time for MLP2520H2R2MT0S1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MLP2520H2R2MT0S1. We look forward to doing business with you.
