Technical Specifications of TP4-R47-R
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | THIN-PAC? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Type | Toroidal |
|---|
| Material - Core | - |
|---|
| Inductance | 470nH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 2.8A |
|---|
| Current - Saturation | 6.3A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 41.1 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.480" L x 0.370" W (12.20mm x 9.40mm) |
|---|
| Height - Seated (Max) | 0.118" (3.00mm) |
|---|
We can supply Eaton part# TP4-R47-R. Use the request quote form to request TP4-R47-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TP4-R47-R. The price and lead time for TP4-R47-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TP4-R47-R. We look forward to doing business with you.
