Technical Specifications of HM53-306R8HLF
| Datasheet |  HM53-306R8HLF datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TT Electronics/BI Magnetics |
|---|
| Series | HM53 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Toroidal |
|---|
| Material - Core | - |
|---|
| Inductance | 6.8μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 11.1A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 8.3 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.874" Dia (22.20mm) |
|---|
| Height - Seated (Max) | 0.547" (13.90mm) |
|---|
We can supply TT Electronics/BI Magnetics part# HM53-306R8HLF. Use the request quote form to request HM53-306R8HLF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number HM53-306R8HLF. The price and lead time for HM53-306R8HLF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# HM53-306R8HLF. We look forward to doing business with you.
