Technical Specifications of IHLP2525CZER2R2M11
| Datasheet |  IHLP2525CZER2R2M11 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Vishay Dale |
|---|
| Series | IHLP-2525CZ-11 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Molded |
|---|
| Material - Core | - |
|---|
| Inductance | 2.2μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 9A |
|---|
| Current - Saturation | 7A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 16.5 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.270" L x 0.255" W (6.86mm x 6.47mm) |
|---|
| Height - Seated (Max) | 0.118" (3.00mm) |
|---|
We can supply Vishay Dale part# IHLP2525CZER2R2M11. Use the request quote form to request IHLP2525CZER2R2M11 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IHLP2525CZER2R2M11. The price and lead time for IHLP2525CZER2R2M11 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IHLP2525CZER2R2M11. We look forward to doing business with you.
