LTC1403AIMSE#TRPBF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | LTC1403AIMSE#TRPBF |
|---|---|
| Manufacturer | Linear Technology |
| Description | 14 Bit Analog to Digital Converter 1 Input 1 SAR 10-MSOP-EP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| LTC1403AIMSE#TRPBF Price |  |
Technical Specifications of LTC1403AIMSE#TRPBF
| Datasheet |  LTC1403AIMSE#TRPBF datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 2.8M |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 2.7 V ~ 3.6 V |
| Voltage - Supply, Digital | 2.7 V ~ 3.6 V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 10-MSOP-EP |
