ADC1213D125HN-C18
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ADC1213D125HN-C18 |
|---|---|
| Manufacturer | IDT, Integrated Device Technology Inc |
| Description | 12 Bit Analog to Digital Converter 2 Input 2 Pipelined 56-VFQFPN (8x8) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ADC1213D125HN-C18 Price |  |
Technical Specifications of ADC1213D125HN-C18
| Datasheet |  ADC1213D125HN-C18 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | IDT, Integrated Device Technology Inc |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 125M |
| Number of Inputs | 2 |
| Input Type | Differential, Single Ended |
| Data Interface | JESD204A |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 2.85 V ~ 3.4 V |
| Voltage - Supply, Digital | 1.65 V ~ 1.95 V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 56-VFQFN Exposed Pad |
| Supplier Device Package | 56-VFQFPN (8x8) |
