AD7783BRUZ
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD7783BRUZ |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 24 Bit Analog to Digital Converter 1 Input 1 Sigma-Delta 16-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| AD7783BRUZ Price |  |
Technical Specifications of AD7783BRUZ
| Datasheet |  AD7783BRUZ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 24 |
| Sampling Rate (Per Second) | 19.79 |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | SPI, DSP |
| Configuration | MUX-PGA-ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | Sigma-Delta |
| Reference Type | External |
| Voltage - Supply, Analog | 2.7 V ~ 3.6 V, 5V |
| Voltage - Supply, Digital | 2.7 V ~ 3.6 V, 5V |
| Features | PGA |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
