TLC7528CPWRG4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TLC7528CPWRG4 |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 8 Bit Digital to Analog Converter 2 20-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TLC7528CPWRG4 Price |  |
Technical Specifications of TLC7528CPWRG4
| Datasheet |  TLC7528CPWRG4 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 8 |
| Number of D/A Converters | 2 |
| Settling Time | 100μs |
| Output Type | Current - Unbuffered |
| Differential Output | No |
| Data Interface | Parallel |
| Reference Type | External |
| Voltage - Supply, Analog | 5 V ~ 15 V |
| Voltage - Supply, Digital | 5 V ~ 15 V |
| INL/DNL (LSB) | ±0.5 (Max), ±0.5 (Max) |
| Architecture | R-2R |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 20-TSSOP |
