MCP4922-E/SL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MCP4922-E/SL |
|---|---|
| Manufacturer | Microchip Technology |
| Description | 12 Bit Digital to Analog Converter 2 14-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MCP4922-E/SL Price |  |
Technical Specifications of MCP4922-E/SL
| Datasheet |  MCP4922-E/SL datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 12 |
| Number of D/A Converters | 2 |
| Settling Time | 4.5μs (Typ) |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | SPI |
| Reference Type | External |
| Voltage - Supply, Analog | 2.7 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.7 V ~ 5.5 V |
| INL/DNL (LSB) | ±2, ±0.2 |
| Architecture | String DAC |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SOIC |
